Description
Slide Switch is for changing circuit by sliding the mini handle of the switch to control the circuit to be ON or OFF.
The Slide Switch is widely used in the electric toy, sound equipments, fax, test instrument equiopments, or other low voltage circuit electronic equipments.
This Slide Switch is with Terminals terminals design for easily welding onto the circuit.
The slide knob is 7mm in height
Make sure this fits by entering your model number.
Product Name : Horizontal Slide Switch;Model No. : SK12F14-G7;Position : 2;Terminal Design : Single Row 3 Terminals
Contact Type : 1P2T;Terminal Width : 0.6mm/ 0.024″;Terminal Pitch : 3mm / 0.12″;Rating : DC 50V, 0.5A
Contacts Resistance : 30Mohm;Insulation Resistance : 100Mohm;Minimum Load : DC 500V;Dielectric Strengths : AC 500V / 1 minute
Life Test : 10000 cycles/ minute;Knob Size : 3 x 2.2 x 7mm / 0.12″ x 0.08″ x 0.27″(L*W*H);Main Body Size(not include Terminals & knob) : 13 x 5.5 x 5mm/ 0.51″ x 0.22″ x 0.2″ (L*W*H);Overall Size : 13 x 12.5 x 9mm/ 0.51″ x 0.49″ x 0.35″ (L*W*H)
Material : Plastic & Metal;Color : As picture shown;Weight : 10g;Package : 10 x Horizontal Slide Switch
